Production Floor Coordinate Measuring machine

Sheffield Discovery II-D8

PC-DMIS Pro Software

X-Axis Travel: 20.0″

Y-Axis Travel: 24.0″

Z-Axis Travel: 16.0″

Accuracy: .0003″

T.H.T. Machining, Inc. uses a Sheffield CMM on the production floor, all operators are trained to use this CMM. It is programmed for each part and each operation to ensure repeatability of the dimension established from first piece inspection. CMM is calibrated and maintained yearly, calibration records on file.

Inspection Optical Comparator

CCP CC-14L Optical Comparator

Screen Size: 14″

X-Axis Travel: 8.0″

Y-Axis Travel: 4.0″

Focus Travel: 1.5″

Lens: 10x, 20x, and 50x Resolution

T.H.T. Machining, Inc. uses a CCP CC-14L Optical Comparator to validate all Final Inspection, First Piece, and In-Process data. Comparator is calibrated and maintained yearly, calibration records on file.

T.H.T. Machining’s Quality Department is certified to the highest standards in the business. Inspectors are required to take the required training to the newet standard every 2 years of the AS13001 training.
